Supports 4 TURBOHD / analog channels + 4 IP channels = 8 channels in total.
H.265+ / H.265 / H.264.
HD-TVI: 8 Megapixel / 5 Megapixel / 2 Megapixel.
HD-CVI: 8 Megapixel / 5 Megapixel / 2 Megapixel.
AHD: 5 Megapixel / 2 Megapixel.
IP: 8 / 6 / 5 / 4 / 2 Megapixel.
Does not support zero channel.
Physical Characteristics:
Power supply: 12 Vdc.
Consumption without hard disk: 15 W.
Operating temperature: -10 ºC to 55 ºC
Dimensions: 260 × 222 × 45 mm (W × D × H)
Weight: 1 Kg without hard disk.
Audio / Alarms / Network / Storage Inputs and Outputs:
Audio input: 1 (RCA, 2.0 Vp-p, 1KΩ).
4 Audio inputs by coaxitron.
Audio output: 1 (RCA, 2.0 Vp-p, 1KΩ).
Alarm input: N/A
Alarm output: N/A
USB interface: 2 rear ports (2.0).
Network interface: 1 port (RJ-45 10/100 Mbps).
Storage capacity (HDD): 1 to 10 TB.
Highlighted Features:
Allows turning off TURBOHD channels to add more IP channels (up to 8 IP channels in total).
To connect IP cameras, a PoE switch is required (not included).
Supports up to 4 channels with ACUSENSE Lite technology (human and vehicle but with motion detection, not analytics).
If IP mode is enabled. This option disables smart functions, such as motion detection. This setting prioritizes IP channel capacity over advanced analytical functions.
Audio, Video and Data on the Same Cable
Audio by Coaxitron on All Channels.
One of the many advantages of new video surveillance systems is audio by coaxitron. By combining a camera with a built-in microphone and a video recorder with audio by coaxitron, you will be able to store video and audio without having to add extra components, as the installation of a camera with a built-in microphone is exactly the same as one without a built-in microphone and yes... you can add cameras with a built-in microphone on all TurboHD channels (the audio by coaxitron function only works on TVI/TurboHD).
