Hospital Warning Light, Four-Color for Presence or Alarm Indication in Room / RS485 BUS / Compatible with NX0019/B, NX1021 and NX0015
- SKU NX0176
- Categoria Automatización e Intrusión > Sistemas de Emergencia > Atención Sociosanitaria
Main Features
- Energy-efficient LEDs
- Excellent side visibility
- Complies with DIN VDE 0834 standard
- Audible alarm
- Requires NX9003 frame
- Compatible with NX0019/B, NX1021 and NX0015
Electrical and Physical Characteristics
- 12 VDC power supply
- 3 fixed lights and 1 RGB light
- Dimensions: 45 x 45 x 30 mm
- Review the complete datasheet
Highlighted Features
The NX0176 four-color warning light allows to indicate different alert situations or other reasons thanks to its four luminous segments of adjustable intensity:
- Different types of alarms
- Presence of different staff profiles (medical, nursing, maintenance, cleaning...)
- Pending tasks in the room
The luminous segments are divided into 3 fixed color lights (white, red, and green) and a fourth RGB light with a configurable color among 16,777,216 possible colors.
Additionally, this light indicator complies with the DIN VDE 0834 standard.
Note: Certification is required for installation and technical support requests.
Usage Examples
Connection is made with 2 pairs of UTP cable to any of the NX0019/B, NX1021, or NX0015 room terminals.
Module Installation
The module includes a frame for direct attachment to a 2x2 inch square box (not included) and the NX9003 decorative frame (not included) is placed.
